- PVC construction offers longer life.
- Molded construction for product consistency.
- Wide chemical compatibility.
- Larger connection for maximum output.
- The unique locator and closure design avoids internal bypass.
- Easy installation and cartridges change-out.
Features
Applications
- Raw water treatment
- Brackish water treatment
- Sewage
- Pre-filtration
- Electroplating
Specifications
MATERIAL | |
---|---|
Housing | AE-716 & AE-732 |
Housing Lock | Stainless Steel Swing Ring Nut |
“O”-ring / Gasket | Silicon / EPDM |
SUITABLE FILTER BAG | |
Size | 7″ X 16″ & 7″ X 32″ |
No. of Filter bag per Vessel | 1 No. |
Bag Collar Type | PP |
Filter Bag Micron | 5 Micron – 250 Micron |
Filter Bag Material | PP |
CONFIGURATION | |
Available Housing Size | 7″ X 16″ & 7″ X 32″ |
Connection Type | uPVC flange ASA#150 |
Connection Size | 2″ Flanged ( 7″ X 16″ & 7″ X 32″) |
OPRATING CONDITIONS | |
Maximum operating pressure | 5 Bar |
Hydro-test pressure | 8 Bar |
CAPACITY | |
Flow Rate | For 7″ X 17″ — 10,000 – 15,000 LPH |
For 7″ X 32″ — 20,000 – 25,000 LPH |
